Recent Projects
SR 44 over St John’s River Bridge Replacement
FDOT project T5706 is a $44 million bridge replacement of the existing Francis P Whitehead bascule bridge on SR 44 over the St Johns River. This project is located on the border of Lake County and Volusia County in FDOT District 5. The new bridge is a 2-lane mid-rise bridge with a 12’ shared use path. The bridge consists of 10 spans totaling 1,656 LF long.
To facilitate the construction of the bridge within the limits of the river, a temporary work trestle designed by GBE was constructed. The main leg of the trestle is 7 spans and stick out 245 LF into the river. There is also one finger coming off the main leg that is 2 spans and approximately 70 LF long. Each pier of this trestle is constructed using 24” pipe pile that averaged about 120 feet long. This temporary work bridge is designed to carry the weight of a fully loaded crane which minimizes the need for barges.
Recent and Ongoing Projects
-
SR. 687 4th Street Bridge (Demolition of Existing Bridge)
Evaluation of existing 1957 prestressed concrete girder bridge to accommodate a Manitowoc 777 crane on top of a deck.
-
SR 9/I-95 Over Nassau River
Development of construction drawings and calculations for the falsework associated with a new set of substructure bents Unser an existing bridge.
-
SR 93 (I-75) at US 301 Interchange Over Manatee River Fender System
Development of shop drawings for the fender structure.
-
NASA Causeway Bridge Replacement
Development of shop drawings for the new bridge fender structure.
-
SR 5/US-1 Over the Loxahatchee River
Development of shop drawings for the new bridge fender structure.
